Products Embedded vision and multi-camera setup - xiX

Embedded vision and multi-camera setup - xiX

OEM type of product - special conditions may apply

  • Fast speed interface with high bandwidth of up to 64 GBit to utilize the full potential of the sensors
  • Osram CMOSIS sensors: CMV2000CMV4000CMV12000, CMV20000, CMV50000
  • Sony Pregius™ sensors: IMX174IMX252IMX250IMX255IMX253, IMX530, IMX531, IMX532
  • Gpixel sensors: GMAX0505, GMAX3265
  • Resolutions range from 2 Mpix to 65 Mpix
  • Ideal platform for aggregation of Multiple camera streams
  • Designed for use with NVIDIA Jetson GPU modules
  • Integrated Canon EF-mount control with dynamic aperture and focus control
  • Remotely usable sensor boards - long distance reach for Embedded vision systems
  • DMA (Direct memory access) ensures an almost non-existent latency of multi-camera setup
  • Compactness and Low power consumption
  • Portability and modularity
  • Low HW and SW overhead
  • HDR Dual ADC capability features with Low and High gain



The xiX cameras are designed for use in Embedded vision systemsMulti-camera line

technical manual fast high speed multi camera Sony CMOS embedded vision setupxiX Manual



CMOSIS Sony CMOS IMX CMV Flat Flex camera USB3 PCIe USB 3.0 USB 3.1



xiX and xiC - Embedded vision cameras Infographics



Overview of various versions and options possible through modularity of the camera architecture.

Clear benefits for classic system integrators or start-ups with new ideas that are offered through the diversity of multiple setups.

All with a small footprint and detachable parts or switchable sets of components.







CMOSIS Sony CMOS IMX CMV Flat Flex camera USB3 PCIe USB 3.0 USB 3.1



xSwitch Infographics of Embedded vision systems



This document explains XIMEA concept for Embedded vision systems.

Topology, cables (e.g. flat-flex ribbon), switches, boards, adapters - the plethora of various elements allowing to assemble a system with a perfect fit for your particular application.

Easy to compile, easy to exchange and suitable for remote operation.







Embedded vision systems applications camera fast small 360 panorama



Applications for embedded camera systems - examples:



360 panorama, Augmented or Virtual Reality (AR, VR), Autonomous self-driving vehicles,

Street/city mapping, Deep learning tasks, Stereo camera systems, portable medical devices,

3D scanning, Entertainment, Photogrammetry, FACS scanning, Face recognition,  Motion capture,

UAV / UAS (drones), Cinematography, Videogrammetry,

LoLa (Low Latency audio visual streaming)







NVIDIA Jetson Embedded Vision systems cameras platform

NVIDIA Jetson TX1/TX2



For Jetson platform customers and machine vision integrators who are designing portable, compact Embedded vision systems with high resolution, high data bandwidth and modular architecture.

xiX cameras and carrier boards are the ideal high bandwidth multi-camera solutions for autonomous, miniature applications in many established and Startup markets.

Unlike other generic product options which are not optimized for customization and extreme size restrictions, xiX cameras and carrier boards offer the smallest form factor and highest speed of data transmission while consuming the least amount of power and including the fastest Time to market path with exhaustive customer support.


Cameras and Accessories

Carrier board for NVIDIA Jetson and cameras
Carrier board for NVIDIA Jetson and cameras



  • Board stack for embedded / multi cameras
  • Compact standalone GPU package
  • Multiple ports for cameras and various peripherals
  • Simultaneous synchronization and triggering
Switches for Multi camera connections
Switches for Multi camera connections



  • Multiple inputs for various interface slots
  • Compact multiplexor for 4 - 12 cameras
  • Single high speed 64 Gbits output cable
  • Simultaneous synchronization and triggering
Adapters, Cables and Accessories
Adapters, Cables and Accessories



  • Interconnects with miscellaneous systems
  • Mini PCIe, M.2, PCIe x4, x8, iPass, USB
  • Flat flex ribbon cables or iPass cables
  • Adapter boards, Hosts, Switches, GPIO

CMOSIS CMV2000 PCIe mono industrial camera
  • 2.2 MPix
  • 2/3" CMOS, Global Shutter
  • AMS CMOSIS CMV2000 Monochrome
  • 340 fps

CMOSIS CMV2000 PCIe color industrial camera
  • 2.2 MPix
  • 2/3" CMOS, Global Shutter
  • AMS CMOSIS CMV2000 Color
  • 340 fps

CMOSIS CMV2000 PCIe NIR industrial camera
  • 2.2 MPix
  • 2/3" CMOS, Global Shutter
  • AMS CMOSIS CMV2000 Near Infrared (NIR)
  • 340 fps

Sony IMX174 fast mono industrial camera
  • 2.3 Mpix with PCIe speed
  • 1/1.2" CMOS, Global Shutter
  • Sony IMX174 Pregius™ Monochrome
  • 166 fps

Sony IMX174 fast color industrial camera
  • 2.3 Mpix with PCIe speed
  • 1/1.2" CMOS, Global Shutter
  • Sony IMX174 Pregius™ Color
  • 166 fps

Sony IMX252 fast mono industrial camera
  • 3.1 Mpix
  • 1/1.8" CMOS, Global Shutter
  • Sony IMX252 Monochrome
  • 218 fps

Sony IMX252 fast color industrial camera
  • 3.1 Mpix
  • 1/1.8" CMOS, Global Shutter
  • Sony IMX252 Color
  • 218 fps

CMOSIS CMV4000 PCIe mono industrial camera
  • 4.2 MPix
  • 1" CMOS, Global Shutter
  • AMS CMOSIS CMV4000 Monochrome
  • 180 fps

CMOSIS CMV4000 PCIe Color industrial camera
  • 4.2 MPix
  • 1" CMOS, Global Shutter
  • AMS CMOSIS CMV4000 Color
  • 180 fps

CMOSIS CMV4000 PCIe NIR industrial camera
  • 4.2 MPix
  • 1" CMOS, Global Shutter
  • AMS CMOSIS CMV4000 Near Infrared (NIR)
  • 180 fps

Sony IMX250 fast mono industrial camera
  • 5 Mpix
  • 2/3" CMOS, Global Shutter
  • Sony IMX250 Monochrome
  • 165 fps

Sony IMX250 fast color industrial camera
  • 5 Mpix
  • 2/3" CMOS, Global Shutter
  • Sony IMX250 Color
  • 165 fps

Sony IMX255 fast mono industrial camera
  • 8.9 Mpix
  • 16.1mm CMOS, Global Shutter
  • Sony IMX255 Monochrome
  • 95 fps

Sony IMX255 fast color industrial camera
  • 8.9 Mpix
  • 16.1mm CMOS, Global Shutter
  • Sony IMX255 Color
  • 95 fps

Sony IMX253 fast mono industrial camera
  • 12.4 Mpix
  • 17.6mm CMOS, Global Shutter
  • Sony IMX253 Monochrome
  • 69 fps

Sony IMX253 fast color industrial camera
  • 12.4 Mpix
  • 17.6mm CMOS, Global Shutter
  • Sony IMX253 Color
  • 69 fps

Sony IMX542 fast mono industrial camera
  • 16.1 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX542 Monochrome
  • 45 fps

Sony IMX542 fast color industrial camera
  • 16.1 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX542 Color
  • 45 fps

Sony IMX532 HDR mono industrial camera
  • 16.1 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX532 Monochrome
  • 45 fps

Sony IMX532 HDR color industrial camera
  • 16.1 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX532 Color
  • 45 fps

Sony IMX541 fast mono industrial camera
  • 20.3 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX541 Monochrome
  • 35 fps

Sony IMX541 fast color industrial camera
  • 20.3 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX541 Color
  • 35 fps

Sony IMX531 HDR mono industrial camera
  • 20.3 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX531 Monochrome
  • 35 fps

Sony IMX531 HDR color industrial camera
  • 20.3 Mpix
  • 1.1" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX531 Color
  • 35 fps

Sony IMX540 fast mono industrial camera
  • 24.5 Mpix
  • 1.2" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX540 Monochrome
  • 30 fps

Sony IMX540 fast color industrial camera
  • 24.5 Mpix
  • 1.2" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX540 Color
  • 30 fps

Sony IMX530 HDR mono industrial camera
  • 24.5 Mpix
  • 1.2" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX530 HDR Monochrome
  • 30 fps

Sony IMX530 HDR color industrial camera
  • 24.5 Mpix
  • 1.2" Sony CMOS Pregius S™, 4th Gen
  • Sony IMX530 Color
  • 30 fps

CMOSIS CMV12000 mono 4K embedded camera
  • 12 Mpix at 133 Fps
  • AMS CMOSIS CMV12000
  • 28 mm Black and white CMOS
  • PCIe flat ribbon cable camera

CMOSIS CMV12000 color 4K embedded camera
  • 12 Mpix at 133 Fps
  • AMS CMOSIS CMV12000
  • 28 mm Color CMOS
  • PCIe flat ribbon cable camera

CMOSIS CMV20000 mono 5K embedded camera
  • 20 Mpix at 33 Fps
  • AMS CMOSIS CMV20000
  • 35 mm Black and white CMOS
  • PCIe flat ribbon cable camera

CMOSIS CMV20000 color 5K embedded camera
  • 20 Mpix at 33 Fps
  • AMS CMOSIS CMV20000
  • 35 mm Color CMOS
  • PCIe flat ribbon cable camera

CMOSIS CMV50000 mono 8K embedded camera
  • 48 Mpix at 30 Fps
  • AMS CMOSIS CMV50000
  • 35 mm Black and white CMOS
  • PCIe flat ribbon cable camera

CMOSIS CMV50000 color 8K embedded camera
  • 48 Mpix at 30 Fps
  • AMS CMOSIS CMV50000
  • 35 mm Full frame Color CMOS
  • PCIe flat ribbon cable camera

Gpixel GMAX0505 mono 5K embedded camera
  • 26 Mpix
  • CMOS sensor - Gpixel GMAX0505
  • 1.1" Global shutter Monochrome
  • 150 Fps @ 10 bit

Gpixel GMAX0505 color 5K embedded camera
  • 26 Mpix
  • CMOS sensor - Gpixel GMAX0505
  • 1.1" Global shutter Color
  • 150 Fps @ 10 bit

Gpixel GMAX0505 mono NIR 5K embedded camera
  • 26 Mpix
  • CMOS - Gpixel GMAX0505RF Red Fox
  • 1.1" Global shutter Monochrome NIR
  • 150 Fps @ 10 bit

Gpixel GMAX3265 mono 8K embedded camera
  • 65 Mpix
  • CMOS sensor - Gpixel GMAX3265
  • 2.3" Global shutter Monochrome
  • 71 Fps @ 10 bit

Gpixel GMAX3265 color 8K embedded camera
  • 65 Mpix
  • CMOS sensor - Gpixel GMAX3265
  • 2.3" Global shutter Color
  • 71 Fps @ 10 bit
