Host card for xiJ cameras - 2 A

Host card for xiJ cameras - 2 A


Suitable for cameras from: xiJ family


  • Host adapter for power delivery to cooled cameras
  • 2-port: both Type-A
  • Type-A Receptacle, USB IF TID 360000145
  • Asmedia ASM3142, USB IF TID 5080000010
  • PCI Express x4 (x2 mode) Gen 3 Host Card
  • Compliant with PCI Express Base Specification Revision 3.0
  • Compliant with Universal Serial Bus 3.1 specification Revision 1.0
  • Compliant with Intel’s eXtensible Host Controller Interface (xHCI)
  • Compliant with PCI Bus Power Management Interface Specification
  • Support USB3.1 and USB2.0 Link Power Management
  • Support independent port power control
  • USB bus power from PCIe 12V (Step-Down)
  • USB bus power from Power Connector (IDE 4-pin or SATA 15-pin)
  • Provides USB 3.0 cable port lock mechanism


xiJ camera family


Set of accessories


Support page
