MT023MG-SY

MT023MG-SY

FOR HIGH VOLUME PROJECTS ONLY



  • 2.3 Mpix Monochrome CMOS camera with Sony IMX174
  • Thunderbolt™ bandwidth of 10 Gbit/s allows 165 Fps in full resolution



USB3 version of the model available in single unit quantity



Link to Thunderbolt™ certified products:

thunderbolttechnology.net/product/ximea-mt023-industrial-camera



Compact, high speed camera for: In-situ optical inspection camera, fast process capturing, e.g. golf club swings, Intelligent Transportation Systems (ITS), Open road tolling and Traffic monitoring, Industrial Automation, Machine Vision facial Recognition, Motion Capture, Automotive crash testingOCR/ OCV, 3D scanning, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Flat panel inspection, Dental, Kiosks, Security, Biometrics and aerial or city mapping (UAV).



API/SDK supports Windows 32/64 and Mac OS X.

Brochure



CONTACT SALES


Specifications:
Part Number MT023MG-SY
Resolution 2.3 MP 1920 x 1200 pixel
Frame rates 165 Fps
Sensor model Sony IMX174
Sensor type CMOS B/W
Sensor size 1/1.2"
Sensor active area 11.3 x 7.1 mm (Diagonal 13.3 mm)
Spectral range 75% @ 525nm
Readout method Global shutter
Pixel size 5.86 µm
Digitization 10 and 12 Bits
Data interface Thunderbolt 10 Gbits
Dynamic range 73 dB
Full Well Capacity 30 500 e-
Readout noise typ. < 7e-
Signal to noise ratio 45 dB
Gain range 0 … 24dB analog, 24 … 48dB analog + digital
Exposure range 39 µs - 3.6 sec
I/O Ports 1x input, 1x optput
Power consumption 4.5 Watt
Lens mount C and CS - mount
Weight 46 grams
Dimensions WxHxD 26 x 26 x 38 mm
Operating temperature 0° … 50°C, RH 20% … 80% non condensing
Storage environment -30° … 60°C, RH 20% … 90% non condesing
