High-speed PCIe cameras

   Newest models from the well known high-speed product line called xiB.
Compact (60 x 60 x 38 mm) camera family utilizing, besides others, the most recent high resolution CMV50000 sensors from ams CMOSIS.
Able to provide 50 Mpix at the speed of 30 fps across distances up to 300m without frame grabbers. Additional outstanding features include Integrated Canon EF-mount interface with remote dynamic aperture and focus control, Windows and Linux support.
PCIe x4 Gen2 interface  with up to 20 GBit / sec and a direct access to and from the computer's memory (DMA image data transfer) as well as Power/GPIO connectors.

USB3 Vision cameras

   xiC - family presents compact USB 3.1 Gen1 camera models, all with newest Sony CMOS Pregius™ sensors.

This USB3 Vision compliant line offers resolutions from 1 to 12 Mpix and all models with IMX174, IMX252, IMX250, IMX255 or IMX253 are available now. Versions with IMX249, IMX265, IMX264, IMX267 and IMX304 could be offered under certain conditions.

Camera technology and design allow fastest data delivery, lowest power consumption with minimal heat dissipation and easy ways of OEM customization of already small and lightweight camera form.

PCI Express Gen 3 with 64 Gbit/s

   xiB-64 - family is a special series of high speed PCIe interface cameras which are equipped with extraordinary fast sensors from Luxima.

Using these sensors with the pixel size of 13.7 µm various camera models can achieve speeds of 3500+ at 1.1 Mpix or 2500+ at 2 Mpix.

Such transfer speed is ensured by the PCIe Gen3 bandwidth that provides an astonishing 64 Gbit/s or 12+ times the speed of USB3.

Contrary to Camera Link or CoaXPress interfaces, these PCI Express cameras do not need any bulky or pricey Frame Grabbers.
