XIMEA camera finder

Find any XIMEA camera by choosing required parameters like: a preselection to a specified camera family

Home
Products
Cameras

Resolution

1.1 Minimum Resolution value MPix Minimum Resolution

65.4 Maximum Resolution value MPix Maximum Resolution

Frame rate

71 Minimum Frame rate value FPS Minimum Frame rate

3709 Maximum Frame rate value FPS Maximum Frame rate

Sensor vendor

Sensor type

Sensor technology

Sensor size

Pixel size

2.5 Minimum Pixel size value µm Minimum Pixel size

13.7 Maximum Pixel size value µm Maximum Pixel size

Shutter type

Dynamic range

53.7 Minimum Dynamic range value dB Minimum Dynamic range

68 Maximum Dynamic range value dB Maximum Dynamic range

Bits per pixel

Binning - on chip

Skipping - on chip

Full Well Capacity

6500 Minimum Full Well Capacity value e- Minimum Full Well Capacity

30000 Maximum Full Well Capacity value e- Maximum Full Well Capacity

Image data interface

PCIe (20 results)

Lens mount

Sensor cooling

Special features

Saturation Capacity

4527.5 Minimum Saturation Capacity value e- Minimum Saturation Capacity

21204 Maximum Saturation Capacity value e- Maximum Saturation Capacity

Enclosure type

Standard housing (20 results)

Camera family

Product status

Total results 20

12 20

CB013MG-LX-X8G3

Luxima LUX13HS Monochrome high speed camera with PCIe X8 Gen 3

Resolution: 1.1 MPixSensor resolution: 1280 x 864 Interface: PCIe X8 Gen 3 Frame rate: 3709 FPSSensor technology: CMOS Sensor size: 4/3" Sensor vendor: Luxima Sensor model: LUX13HS

CB013CG-LX-X8G3

Luxima LUX13HS Color high speed camera with PCIe X8 Gen 3

CB019CG-LX-X8G3

Luxima LUX19HS Color high speed camera with PCIe X8 Gen 3

Resolution: 2 MPixSensor resolution: 1920 x 1080 Interface: PCIe X8 Gen 3 Frame rate: 2279 FPSSensor technology: CMOS Sensor size: 4/3" Sensor vendor: Luxima Sensor model: LUX19HS

CB019MG-LX-X8G3

Luxima LUX19HS Monochrome high speed camera with PCIe X8 Gen 3

CB024MG-GP-X8G3-SFF

Gpixel GSPRINT4502 Monochrome high speed camera with PCIe X8 Gen 3

Resolution: 2.4 MPixSensor resolution: 2048 x 1216 Interface: PCIe X8 Gen 3 Frame rate: 2570 FPSSensor technology: CMOS Sensor size: 2/3" Sensor vendor: Gpixel Sensor model: GSPRINT4502

CB024CG-GP-X8G3-SFF

Gpixel GSPRINT4502 Color high speed camera with PCIe X8 Gen 3

CB100CG-GP-X8G3-SFF

Gpixel GSPRINT4510 Color high speed camera with PCIe X8 Gen 3

Resolution: 10 MPixSensor resolution: 4608 x 2176 Interface: PCIe X8 Gen 3 Frame rate: 668 FPSSensor technology: CMOS Sensor size: 4/3" Sensor vendor: Gpixel Sensor model: GSPRINT4510

CB100MG-GP-X8G3-SFF

Gpixel GSPRINT4510 Monochrome high speed camera with PCIe X8 Gen 3

CB120CG-CM-X8G3

CMOSIS CMV12000 Color high speed camera with PCIe X8 Gen 3

Resolution: 12.5 MPixSensor resolution: 4096 x 3072 Interface: PCIe X8 Gen 3 Frame rate: 335 FPSSensor technology: CMOS Sensor size: APS-C Sensor vendor: CMOSIS Sensor model: CMV12000

CB120MG-CM-X8G3

CMOSIS CMV12000 Monochrome high speed camera with PCIe X8 Gen 3

CB160CG-LX-X8G3

Luxima LUX160 Color high speed camera with PCIe X8 Gen 3

Resolution: 16.1 MPixSensor resolution: 4704 x 3424 Interface: PCIe X8 Gen 3 Frame rate: 311 FPSSensor technology: CMOS Sensor size: 4/3" Sensor vendor: Luxima Sensor model: LUX160

CB160MG-LX-X8G3

Luxima LUX160 Monochrome high speed camera with PCIe X8 Gen 3

1/2
