  • 4.2 Megapixels 4/3" Black and White CCD camera with Onsemi (Truesense) KAI-4021 or KAI-4022
  • FireWire Interface. Peltier TEC Cooled


Scientific grade, compact camera for: Flat panel inspection, Microscopy, Ophthalmology, Pathology, Histology, Intelligent Traffic Systems, Fluorescence, Low light, Bar code reading, Astronomy, Digital Radiography, Bioluminescence, Biology, Chemiluminescence and many more.


Check conditions for the Taped Cover Glass or without microlens sensor model.





Resolution 4.2 MP 2048x2048 pixels
Sensor type CCD B/W
Sensor model KODAK KAI-4021
Sensor size 4/3"
Sensor active area 16.67 x 16.05 mm
Pixel size 7.4 μm
Bits per pixel 8, 10, 12, 14
Acquisition gain 2.5±0.3 ē/ADU
Acquisition noise typ. 3 ē
Acquisition noise max. 5 ē
Readout noise typ. 12 ē
Dynamic range Typ. 70 dB
Frame rates 6 Fps
On-chip binning 1x1, 2x2, 4x4, 6x6
Image data interface IEEE1394A
Data I/O GPIO 2IN, 2OUT, Serial Port
Power requirements 5-12V 1.8 Watt typ. 3.8 Watt with cooling ON
Cooling Peltier TEC
Lens mount C-Mount
Weight 250 grams
Dimensions WxHxD 60 x 60 x 35 mm
Customs tariff code 8525 80 30
