Hyperspectral Linescan USB3 camera 150 bands 470-900nm

Hyperspectral Linescan USB3 camera 150 bands 470-900nm
  • Linescan model
  • Scans: up to 850 lines/sec
  • 150 Spectral bands
  • Spectral range 470-900 nm
  • Spatial resolution equivalent: 2048 x 5 lines in 3 nm steps
  • Smallest and lightest Hyperspectral camera: 26 x 26 x 31 mm, 32g
  • 1.6 Watt and overall SWAP are ideal for Embedded vision systems
  • Each camera is spectrally calibrated
  • USB3 Vision Compliant - speed 170 datacubes/s
  • PCIe interface version - speed 340 datacubes/s



Applications: Precision Agriculture, Remote Sensing, Forensics, Counterfeit, Waste recycling, DNA sequencers/flow cytometers, Medical Imaging (cancer cells inspection), Endoscopy, Fluorescence, Photoluminescence, Ophthalmology, Skin tones/tissue analysis, Material and Life science microscopy, Terrestrial/maritime earth observation, Space exploration, Astronomy, Environmental Monitoring, Security, Spectroscopy instrumentation, Optical sorting, Pharmaceutical, Food inspection (quality grading), Defect detection, UAV



Linescan Hyperspectral imaging (HSI) camera smallest sensor

Brochure



Manual



Product page



Support page



CONTACT SALES




Specifications:
Part Number MQ022HG-IM-LS150-VN2
Resolution 2048 × 5
Frame rates up to 850 lines/sec
Sensor model IMEC CMV2K-LS150
Sensor type CMOS, Hyperspectral filters added at wafer-level
Sensor size 2/3"
Spectral range 470-900 nm
Spectral bands 150 Spectral Bands
Readout method Linescan wedge
Pixel size 5.5 µm
Digitization 8, 10 bit RAW pixel data
Data interface USB 3.1 Gen1 or PCI Express (xiX camera model)
I/O Ports GPIO IN, OUT
Power consumption 1.6 Watt
Lens mount C or CS Mount
Weight 32 grams
Dimensions WxHxD 26 x 26 x 31 mm
Operating temperature 0 - 50 °C
Customs tariff code 8525.80 30 (EU) / 8525.80 40 (USA)
ECCN EAR99
Last Updated: 28 November 2020, 23:29
