MD120CU-SY

MD120CU-SY
  • 12 Megapixel Color CCD (Sony ICX834) Camera with USB 3.0
  • Multi-Tap (Quad Tap) readout from 4 channels allows exceptional 15 Fps

Scientific quality camera with enhanced sensitivity and low readout noise for all branches of life and material science like:

Semiconductor wafer scanning, Flat panel inspection, printed circuit board (PCB) examination, Cell Biology, Astronomy, Medical, Microscopy, Ophthalmology and Retinal imaging, Pathology, Histology, Intelligent Traffic Systems, Fluorescence, Low light, Biometrics, Industrial Automation and others.

Brochure



Accessories



Support pages



CONTACT SALES


Specifications:
Resolution 12 MP 4242 x 2830 pixel
Sensor type CCD RGB Color
Sensor model SONY ICX834 AQG
Sensor size 16 mm
Sensor active area 13.2 x 8.8 mm
Pixel size 3.1 µm
Bits per pixel 8, 10, 12, 14 Bits
Readout noise typ. 7.8 / 9.3 / 16.6 e-
Dynamic range 63.5 / 61.7 / 57.6 dB
Signal to noise ratio 41.1 / 41.1 / 41.0 dB
Exposure range 60us - 1500s
Frame rates 15 Fps
On-chip binning YES
Trigger to exposure delay YES
Image data interface USB 3.0 Superspeed
Data I/O 2IN/2OUT
Power requirements 4.9 Watt (typically*)
Lens mount C-Mount
Weight 320 grams
Dimensions WxHxD 60 x 60 x 38 mm
Customs tariff code 8525.80 30 (EU) / 8525.80 40 (USA)
ECCN EAR99
Last Updated: 25 November 2017, 01:54
