- Small dimensions: 26 x 26 x 33 mm, 38 grams
- 3.1 Mpix
- 122 fps (up to 218 Fps with xiX)
- Monochrome Sony CMOS Pregius™
- With flat ribbon flex cable ideal for Embedded vision systems
- Camera with USB 3.1 Interface - USB3 Vision Compliant
2K camera Applications:
In-situ optical inspection camera, fast process capturing, e.g. Golf club swings, Intelligent Transportation Systems (ITS), Open road tolling and Traffic monitoring, Industrial Automation, Machine Vision, Facial Recognition, Motion Capture, Automotive crash testing, OCR/ OCV, 3D scanning, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Flat panel inspection, Dental, Kiosks, Security, Biometrics and more
Check conditions for the model version with Sony IMX265 sensor.
Brochure
Accessories
USB3 Zone
3D / 2D files
Manual
CONTACT SALES
Specifications: | |
| Part Number | MC031MG-SY |
| Resolution | 3.1 MP 2064 x 1544 pixels |
| Frame rates | 122 fps |
| Sensor model | Sony IMX252 |
| Chroma | Monochrome |
| Sensor type | CMOS Matrix B/W |
| Sensor size | 1/1.8" |
| Sensor active area | 7.1 x 5.3 (Diagonal 8.9 mm) |
| Readout method | Global shutter |
| Pixel size | 3.45 µm |
| Digitization | 8, 10, 12 bit |
| Data interface | USB 3.1 Gen 1 |
| Dynamic range | 70.9 dB |
| Full Well Capacity | 9900 e- |
| On-chip binning | 1x2 (and 2x2 Skipping) |
| Dark current | 2.1 e- |
| Readout noise typ. | 2.32 e- |
| Signal to noise ratio | 40.3 dB |
| Exposure range | 1µs to 30sec, in steps of 5.29µs |
| I/O Ports | GPIO IN, OUT |
| Power consumption | 2.75 Watt |
| Lens mount | C or CS Mount |
| Weight | 38 grams |
| Dimensions WxHxD | 26 x 26 x 33 mm |
