MC089MG-SY

MC089MG-SY
  • Small dimensions: 26 x 26 x 33 mm, 38 grams
  • 8.9 Mpix at 43 fps (up to 95 Fps with xiX)
  • With flat ribbon flex cable ideal for Embedded vision systems
  • USB3 Vision Compliant



8.9 MP Monochrome Sony CMOS Pregius™ Camera with USB 3.1 interface



4K camera Applications: In-situ optical inspection camera, fast process capturing, e.g. golf club swings, Intelligent Transportation Systems (ITS), Open road tolling and Traffic monitoring, Industrial Automation, Machine Vision, Facial Recognition, Motion Capture, OCR/ OCV, 3D scanning, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, PCB and Flat panel inspection, Dental, Kiosks, Security, Biometrics and more



NOTE: Please check MOQ and conditions for the version with Sony IMX267



Brochure



Accessories



USB3 Zone



3D / 2D files



Manual



CONTACT SALES




Specifications:
Part Number MC089MG-SY
Resolution 8.9 MP 4112 x 2176 pixels
Frame rates 43 fps
Sensor model Sony IMX255 LLJ-C
Sensor type CMOS Matrix B/W
Sensor size 1"
Sensor active area 14.2 x 7.5 (Diagonal 16.1 mm)
Readout method Global shutter
Pixel size 3.45 µm
Digitization 8, 10, 12
Data interface USB 3.1 Gen 1
Dynamic range 70.5 dB
Full Well Capacity 9800 e-
On-chip binning 1x2, 2x2 (and Skipping)
Dark current 3.9 e-
Readout noise typ. 2.4 e-
Signal to noise ratio 40.3 dB
Exposure range 1µs to 30sec, in steps of 10.54µs
I/O Ports GPIO IN, OUT
Power consumption 3.25 Watt
Lens mount C or CS Mount
Weight 38 grams
Dimensions WxHxD 26 x 26 x 33 mm
Operating temperature 50 °C
Last Updated: 29 March 2024, 05:08
