Sony IMX531 HDR mono industrial camera

Sony IMX531 HDR mono industrial camera
MTO - Made to order
  • Small dimensions: 26 x 26 x 31 mm
  • 20.3 MP Monochrome BSI - backside illuminated
  • 35 fps at full resolution
  • Sony CMOS Pregius S™ 4th Generation IMX531 B/W camera
  • With flat ribbon flex cable ideal for Embedded vision systems
  • Additional features like Dual ADC - HDR mode


High resolution camera Applications:

VR an AR, Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, Industrial Automation, Machine Vision, Facial Recognition, Motion Capture, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Dental, Security, Biometrics and more






PCIe Zone


3D / 2D files






Part Number MX203MG-SY-X2G2-Fx-HDR
Resolution 20.3 MP 4504 x 4504
Frame rates 35 Fps (8bit), 30 Fps (10bit), 25 Fps (12bit)
Sensor model Sony Pregius-S IMX531
Chroma Monochrome, B/W
Sensor type CMOS, BSI - Backside illuminated
Sensor size 1.1"
Sensor active area 12.34 x 12.34 mm
Readout method Global Shutter
Pixel size 2.74 x 2.74 μm
Digitization 8, 10, 12
Data interface PCI Express Gen2 (PCIe)
Dynamic range 70 dB
Full Well Capacity 9500 e-
On-chip binning 2x2
Readout noise typ. 1.1 e-
Signal to noise ratio 40 dB
Gain range 24 dB
Exposure range 14 μs to 30 s, in steps of 11.57 μs
Power consumption 3.6 Watt
Lens mount C-Mount or CS-mount
Weight 38 grams
Dimensions WxHxD 26 x 26 x 31 mm
