MTO - Made to order
- Small dimensions: 26 x 26 x 33 mm
- 16.1 Mpix Color
- 23 fps (up to 158 Fps with xiX-Xtreme)
- Sony IMX542 CMOS Pregius S™ BSI - backside illuminated sensor
- With flat ribbon flex cable ideal for Embedded vision systems
- Camera with USB 3.1 Interface - USB3 Vision Compliant
Available with Sony IMX532 and HDR functionality
High resolution camera Applications:
VR an AR, Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, Industrial Automation, Machine Vision, Facial Recognition, Motion Capture, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Dental, Security, Biometrics and more
Brochure
Accessories
USB3 Zone
3D / 2D files
Manual
CONTACT SALES
Specifications: | |
| Part Number | MC161CG-SY |
| Resolution | 16.1 MP 5320 x 3032 pixels |
| Frame rates | 23 Fps (8 bit), 18 Fps (10 bit), 15 Fps (12 bit) |
| Sensor model | Sony Pregius-S IMX542 AAQJ-C |
| Chroma | Color, RGB |
| Sensor type | CMOS, BSI - Backside illuminated |
| Sensor size | 1.1" |
| Sensor active area | 14.58 x 8.31 mm |
| Readout method | Global Shutter |
| Pixel size | 2.74 μm |
| Digitization | 8, 10, 12 bit |
| Data interface | USB 3.1 Gen 1 |
| Dynamic range | 70 dB |
| Full Well Capacity | 10 000 e- |
| On-chip binning | 2x2 |
| Readout noise typ. | 2.5 e- |
| Signal to noise ratio | 40 dB |
| Gain range | 24 dB |
| Exposure range | 9 µs to 30 s, step 7 µs |
| I/O Ports | GPIO IN, OUT |
| Power consumption | 3.2 Watt |
| Lens mount | C-Mount or CS-mount |
| Weight | 38 gram |
| Dimensions WxHxD | 26 x 26 x 31 mm |
