Gpixel GMAX0505 color 5K embedded camera

MTO - Made to order

26 Mpix color
150 FPS @ 10bit
World's smallest Global shutter pixel with only 2.5 µm
1.1" CMOS sensor: Gpixel GMAX0505
High resolution and fast speed industrial camera
No Frame grabber with PCIe interface and 64 Gbps bandwidth
High Dynamic range, Low noise, minimal latency, DMA
With flat ribbon flex cable ideal for Embedded vision systems

5K, compact, high speed camera for:

Flat panel inspection (FPD), printed circuit board (PCB) examination, Pill sorting (laser 3D method), solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports broadcast and entertainment, UAV and Autonomous, Unmanned vehicles, Photogrammetry, surveying, aerial or city mapping, 360 panorama and more.

Note: Check conditions for Taped Cover Glass sensor model

Brochure

Manual

Accessories

Camera family

Embedded pages

CONTACT SALES

Specifications:
Part Number	MX262CG-GP-X8G3
Resolution	26.2 MP 5120 x 5120 pixels
Frame rates	150 fps (8bit), 150 fps (10bit), 41 fps (12bit)
Sensor model	GPixel GMAX0505 DVC HLT
Chroma	Color, RGB
Sensor type	CMOS
Sensor size	1.1"
Sensor active area	12.8 x 12.8 mm (Diagonal 18.1 mm)
Spectral range	400-1000 nm
Readout method	Global shutter
Pixel size	2.5 µm
Digitization	10 and 12 bits
Data interface	PCIe Gen3 x8 (64 Gbits)
Dynamic range	63 dB (at 12bits)
Full Well Capacity	4 700 e- (at 12bits)
Dark current	4 e- (at 12bits)
Readout noise typ.	2.7 e- (at 12bits)
Signal to noise ratio	37 dB (at 12bits)
Exposure range	11 µs to 1.05 s, step 1.29 µs
I/O Ports	GPIO 2IN, 2OUT, Serial Port
Power consumption	14 Watt maximum
Lens mount	C-mount or active Canon EF-mount, via optional lens adapter
Weight	250 grams
Dimensions WxHxD	60 x 70 x 36 mm
Cooling	Fan or Water module
