CMOSIS CMV20000 mono 5K embedded camera

CMOSIS CMV20000 mono 5K embedded camera
MTO - Made to order

  • 20 Mpix
  • Monochrome
  • CMOSIS CMV20000 Osram AMS
  • 35mm Full frame CMOS Global shutter camera
  • With flat ribbon flex cable ideal for Embedded vision systems
  • PCIe speed of 20 Gbit/s allows 33 Fps at 12 bit



5K, compact, high speed camera for:

Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, aerial or city mapping.



Check conditions for the Taped Cover Glass sensor model.



Brochure



Accessories



Manual



Embedded pages



Support page



CONTACT SALES




Specifications:
Part Number MX200MG-CM
Resolution 20 MP 5120 x 3840 pixels
Frame rates 33 Fps
Sensor model AMS CMOSIS CMV20000 1E5M1PA
Chroma Monochrome, B/W
Sensor type CMOS
Sensor size 2.56” (Full frame 35mm)
Sensor active area 32.77 x 24.58 mm (Diagonal 41 mm)
Readout method Global shutter
Pixel size 6.4 x 6.4 μm
Digitization 12 bits
Data interface PCI Express Gen2 (PCIe) 20 Gbits
Dynamic range 66 dB
Full Well Capacity 15 000 e-
Exposure range 94 µs to 1.05 s, step 8 µs
I/O Ports 2IN/2OUT
Power consumption 7 Watt
Lens mount EF-mount
Weight 156 grams
Dimensions WxHxD 33 x 60 x 60 mm
Cooling Heatsink optional
