Sony IMX542 fast mono industrial camera
MTO - Made to order
- Small dimensions: 26 x 26 x 31 mm
- 16.1 Mpix at 45 fps
- With flat ribbon flex cable ideal for Embedded vision systems
- PCI Express Compliant
16.1 MP Monochrome BSI Sony CMOS Pregius S™ 4th Generation Camera
Specifications are preliminary and subject to change
High resolution camera Applications: VR an AR, Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, Industrial Automation, Machine Vision, Facial Recognition, Motion Capture, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Dental, Security, Biometrics and more
Check conditions for the model version with Sony IMX532 monochrome sensor.
Brochure
Accessories
Embedded Zone
Manual
CONTACT SALES
Specifications: | |
Part Number | MX161MG-SY |
Resolution | 16.1 MP 5320 x 3032 |
Frame rates | 45 Fps (8bit), 38 Fps (10bit), 31 Fps (12bit) |
Sensor model | Sony Pregius-S IMX542-AAMJ-C |
Chroma | Monochrome, B/W |
Sensor type | CMOS, BSI - Backside illuminated |
Sensor size | 1.1" |
Sensor active area | 14.58 x 8.31 mm |
Readout method | Global Shutter |
Pixel size | 2.74 x 2.74 μm |
Digitization | 8, 10, 12 |
Data interface | PCI Express Gen2 (PCIe) |
Dynamic range | 70 dB |
Full Well Capacity | 9500 e- |
Readout noise typ. | 2.1 e- |
I/O Ports | GPIO IN, OUT |
Lens mount | C-Mount or CS-mount |
Dimensions WxHxD | 26 x 26 x 31 mm |
