MTO - Made to order
- Small dimensions: 26 x 26 x 31 mm
- 5 Mpix
- Monochrome
- Sony IMX250 CMOS Pregius™
- Flat ribbon flex cable ideal for Multi camera setup and Embedded vision
- 165 fps with PCI Express Gen2 x2 lanes
High resolution Applications:
Ultra-fast 3D scanning, Miniature and accurate robotic arms, Industrial and Factory Automation, Machine Vision, High definition Motion capture, Cinematography and Entertainment, 360 Panorama, Face recognition, Eye Tracking, Body scanner, People counting, Broadcasting, Sports Automation & Motion Tracking, Rapid process capturing, e.g. golf club swings, baseball, tennis, hockey, VR and AR (virtual or augmented reality), Autonomous vehicles and more
Brochure
Accessories
Embedded Zone
Manual
Support page
CONTACT SALES
Specifications: | |
| Part Number | MX050MG-SY |
| Resolution | 5 MP 2464 x 2056 pixels |
| Frame rates | 165 Fps (8bit), 146 Fps (10bit), 90 Fps (12bit) |
| Sensor model | Sony IMX250 LLR-C |
| Chroma | Monochrome |
| Sensor type | CMOS Matrix B/W |
| Sensor size | 2/3" |
| Sensor active area | 8.5 x 7.1 (Diagonal 11.1 mm) |
| Readout method | Global shutter |
| Pixel size | 3.45 µm |
| Digitization | 8, 10, 12 bit |
| Data interface | PCI Express Gen2 (PCIe) 10 Gbits |
| Dynamic range | 70.8 dB |
| Full Well Capacity | 9800 e- |
| On-chip binning | 1x2 (and 2x2 Skipping) |
| Dark current | 3.9 e- |
| Readout noise typ. | 2.32 e- |
| Signal to noise ratio | 40.3 dB |
| Gain range | 24 dB |
| Exposure range | 1 µs to 30 sec, step 2.89 µs |
| I/O Ports | GPIO IN, OUT |
| Power consumption | 3.7 Watt |
| Lens mount | C-Mount or CS-mount |
| Weight | 30 grams |
| Dimensions WxHxD | 26 x 26 x 31 mm |
