Sony IMX411 high resolution color BSI camera

Sony IMX411 high resolution color BSI camera
COMING SOON

  • 151 Mpix camera with Sony IMX411 BSI
  • Medium format Color CMOS - Backside illuminated
  • PCIe speed of 32 Gbit/s allows 2 Fps at 16 bit
  • With flat ribbon flex cable ideal for Photogrammetry



Medium format, high resolution, compact camera for: Photogrammetry, Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, aerial or city mapping.



Check conditions for various types of Cooling - Liquid, Air or Heatsink.

Specifications are preliminary and subject to change

Brochure



Firefly connection



MTP connection



Manual



2D drawing



CONTACT SALES


Specifications:
Part Number MX1510CR-SY-X4G3
Resolution 151 MP 14192 x 10640
Frame rates 2 Fps at 16 bit
Sensor model Sony IMX411 AQR-C
Chroma Color RGB
Sensor type CMOS BSI - Backside illuminated
Sensor size Medium format (Type 4.2)
Sensor active area 53.36 x 40.01 mm (Diagonal 66.7 mm)
Readout method Rolling shutter
Pixel size 3.76 µm
Digitization 16, 14, 12, 11 bit
Data interface PCI Express Gen3 x4 (PCIe)
Dynamic range 78 dB
Full Well Capacity 50 000 e-
On-chip binning 1x1, 2x2, 3x3
Readout noise typ. 1 e-
Gain range 36 dB
Exposure range 90µs to 12s
I/O Ports 2IN/2OUT
Power consumption TBD
Lens mount M72
Weight TBD
Dimensions WxHxD 80 x 80 x 45 mm
Cooling Fan or Water or Heatsink
Customs tariff code 8525.80 30 (EU) / 8525.80 40 (USA)
ECCN EAR99
